Features:

1. simple and compact structure with light weight, easy to assemble and disassemble.

2. low torque with 90°,  easy to open and close with high   speed.

3. small flow resistance, flow curve goes in slope line, power saving.

4. customised products according to specific materials requirements of the client, suitable for various gases and  environment.

Application:

Butterfly valves are used for regulating and cutting off the medium flow in the pipeline;

suitable for conveying pipelines of corrosive and non-corrosive fluid medium in furnace,coal gas, natural gas, LPG, city gas, hot&cold air, chemical smelting and power generation environmental  protection engineering systems.
